I am a Reader in the School of Physics and Astronomy at Cardiff University specialising in the development of instrumentation for millimetre and sub-millimetre astronomy. Observing at these long wavelengths provides us with a unique view of our Universe but requires highly sensitive and specialised camera systems operated on telescopes located at high altitude (dry) sites or on balloon and satellite-based observatories.  Advancing technology in this field includes research and development in superconducting detector technology, superconducting filter-banks and RF signal manipulation, cryogenics, quasi-optical components and filters and end-to-end imaging systems. I am currently the Principal Investigator of the MUSCAT project building a large format millimetre wave camera for the Large Millimetre Wave Telescope (LMT) in Mexico City. This is an exciting project that has developed new collaborative links between the UK and Mexican research communities and seen researchers from both countries working together to share knowledge and deliver novel instrumentation capabilities to the LMT.

My work in astronomy instrumentation has also led to commercial applications of my research resulting in the formation of a spin-out company - Sequestim Ltd.

http://muscat.astro.cf.ac.uk/wp-content/uploads/2018/03/cropped-1054917504.jpg

Publication

2024

2023

2022

2021

2020

2019

2018

2017

2016

2015

2014

2013

2012

2011

2010

2008

2007

  • Doyle, S. M., Naylon, J. A., Mauskopf, P. D., Porch, A. and Dunscombe, C. J. 2007. Lumped element kinetic inductance detectors. Presented at: 18th International Symposium on Space Terahertz Technology 2007 (ISSTT 2007), Pasadena, CA, USA, 21-23 March 2007 Presented at Karpov, A. ed.18th International Symposium on Space Terahertz Technology 2007 (ISSTT 2007). International Symposium on Space Terahertz Technology ( ISSTT ) NY: International Symposium on Space Terahertz Technology ( ISSTT ) pp. 170-177.

2006

  • Doyle, S. M., Naylon, A. J., Cox, J., Mauskopf, P. D. and Porch, A. 2006. Kinetic inductance detectors for 200 micron astronomy. Presented at: Proceedings of 2006 SPIE, mm and sub-mm detectors for astronomy, Orlando, Florida, Vol. 6275.
  • Doyle, S. M., Naylon, J., Cox, J., Mauskopf, P. D. and Porch, A. 2006. Kinetic inductance detectors for 200μm astronomy. Presented at: Millimeter and Submillimeter Detectors and Instrumentation for Astronomy III, Orlando, FL, USA, 29-31 May 2006 Presented at Zmuidzinas, J. et al. eds.Proceedings. SPIE 6275, Millimeter and Submillimeter Detectors and Instrumentation for Astronomy III. Vol. 6275. Bellingham, WA: The International Society for Optical Engineering, (10.1117/12.670200)

2005

Cynadleddau

Erthyglau

Gosodiad

Gwefannau

Research

My research focuses on the area of detector and instrument development for millimetre, sub-millimetre and Terahertz imaging for astronomy and commercial applications. Detecting light at the long wavelengths is challenging as most room temperature objects radiate at these wavelengths and that the photon energy is too low to make use of conventional semiconductor based systems such as Charged Coupled Devices (CCDs). Performing sensitive imaging at these long wavelengths therefore requires working at cryogenic temperatures typically below 1K (-272°C) and using novel detector technologies that make use of superconducting material properties to convert light into a measurable output. I lead a group of researchers and technical staff that continues to develop instrumentation and detector arrays based on Kinetic Inductance Detectors as well as new compact continuous sub-Kelvin cryogenic coolers.

Kinetic Inductance Detectors

One of the significant outputs of my research has been the invention and development of the Lumped Element Kinetic Inductance Detector (LEKID). This is a variant of the Microwave Kinetic Inductance Detector (MKID) that has properties to enable direct coupling to light (like in a CCD pixel) and convenient coupling to microstrip structures. The LEKID is a superconducting, high quality factor microwave resonator consisting of a planar capacitor-inductor circuit. The inductor has two components – a fixed geometrical inductance Lg and a kinetic inductance Lk resulting in a resonant frequency F0=1/[(Lg+Lk)C]0.5 (typically 0.5-3 GHz). The absorption of a photon with energy greater than the superconducting band gap (hν > 2Δ typically around 90GHz for aluminium based devices) splits paired electrons in the superconducting inductive section modifying F0 though an increase in Lk. This response to absorbed optical power is sensed by measuring the shift in the amplitude and phase of a fixed microwave tone propagated along a microwave feed line to which a LEKID is coupled. This is demonstrated in figure 1.

https://www.astro.cf.ac.uk/~spxsmd/Personal_Page_Figure_1.png

By their very nature, KIDs are naturally multiplexed in the frequency domain and have demonstrated multiplexing ratios of order 1000 detectors/readout channel over readout bandwidths of 2GHz [1]. Furthermore, KID devices only require a single cryogenic amplifier and a pair of coaxial lines to readout each channel leading to a dramatic reduction in the complexity of cryogenic readout electronics and overall focal plane cost compared to rival technologies such as Transition Edge Sensors (TES). KID based focal planes have also demonstrated photon noise limited performance on ground-based mm-wave instruments such as NIKA-2 [2] where the group at Cardiff collaborated on the detector and optical filtering development.

Compact and continuous sub-Kelvin cooling platforms

Our group has been working in collaboration with Chase Cryogenics to develop compact and continuous cooling platforms based upon sorption and dilution refrigerator technology. This work has been proven in the MUSCAT instrument where continuous operation at 130mK under an optical load has been achieved continuously in a self-contained system. The principle is that a pair of standard sorption coolers are run sequentially to provide pre-cooling to a miniature dilution refrigerator unit [3]. The miniature dilution unit runs in a similar way to a standard dilution refrigerator but circulation of the Helium-3 is created through a convective effect. Such a system does not require large volumes of costly Helium-3 nor does it require a bulky room temperature gas handling system. The unit is fully automated and has been proven to maintain its base temperature for months at a time. The entire system is pre-cooled with a commercially available Pulse Tube Cooler (PTC) meaning that no liquid cryogens are required, and the entire system can be controlled remotely.

https://www.astro.cf.ac.uk/~spxsmd/Personal_Page_Figure_2.png

MUSCAT – Full Instrument Development

The experience developed in cryogenics and detector design and fabrication has enabled our group to build an end-to-end cryogenic astronomical camera operating at 300GHz (1mm). The Mexico UK Sub-millimetre Camera for Astronomy (MUSCAT) was developed as part of a knowledge exchange program between the UK and Mexico resulting in a full camera being built for installation at the Large Millimeter Telescope (LMT) in Mexico in early 2021. The camera's focal plane was designed to be simple and cost effected and can be replicated and adapted by our Mexican partners in future configurations. Using the compact and simple cryogenic sub-Kelvin coolers developed by the group means that MUSCAT can be retrofitted with new focal plane technologies and filtering at the site with minimal effort. Ths makes MUSCAT a versatile instrument platform. The Camera is now fully commissioned in the lab and has demonstrated photon noise limited performance meaning the system has reached the fundamental limits in terms of sensitivity. More details about this project can be found here.

https://www.astro.cf.ac.uk/~spxsmd/Personal_Page_Figure_3.png

Imaging systems for industry

Our group has also worked with a commercial partner Sequestim to produce passive security imaging for airport passenger and goods vehicle screening using the technology developed for astronomy. Many materials including clothing and truck tarpaulins are transparent to millimetre and sub-millimetre light meaning we can detect hidden objects beneath these materials. Importantly, the combination of simplified cryogenics and large format arrays of sensitive detectors makes this approach commercially viable. Another important benefit of this approach is that it is purely passive. Unlike rival systems, our camera does not need to irradiate the object to be screened meaning it is safe for humans and can work at ranges of up to 20 meters. The versatility of such a system means that is can screen people and vehicles on the move, drastically improving security screening times. Further information about Sequestim can be found here.

https://www.astro.cf.ac.uk/~spxsmd/Personal_Page_Figure_4.png
